      GLEEBLE system for physical simulation and thermomechanical characterisation in metallurgy processes

      Sistema GLEEBLE de simulación física y caracterización termomecánica en procesos metalúrgicos

      TECNALIA’s GLEEBLE 3800 system is a physical simulator of thermo-mechanical processes in metal alloys, such as hot rolling, forging, hot stamping, HAZ in welding and the mapping of forming.

      Description

      The system is made up of the following equipment:

      • Mobile conversion unit.
      • Transformer.
      • Test chamber (vacuum and controlled atmosphere).
      • Mobile axis.
      • Servo-hydraulic system.
      • Hydraulic pump.
      • Water cooler.
      • Channels for thermocouples.
      • Load cell.

      There is also an external hardening system, and axial and diametral strain gauges.

      It has a tool for anchoring the different clamps (cylindrical and flat test specimens) for hot tensile tests, SICO tests, post-deformation dilatometry tests, thermal fatigue tests, etc. As a secondary tool it has an adapter for compression tests.

      Its main characteristics are:

      • “Direct resistance” heating thermal system (heating speed up to 10,000 ºC/s)
      • Mechanical system with precise control of mechanical variables (axis movement, applied force)
      • Transverse isothermal planes. Axial temperature gradient.
      • Process simulation: hot rolling, forging, hot stamping, HAZ in welding and the mapping of forming, etc.
      • Materials testing: thermal cycle tests, hot tensile tests (ductility), hot uniaxial compression tests (true stress-deformation curves), susceptibility cracking (SICO) tests, post-deformation dilatometry tests, thermal fatigue tests, fusion and solidification, etc.

      Aimed at:

      • Companies devoted to manufacturing or transforming metal alloy products by means of thermo-mechanical processes. In particular, foundry and steel processes.
